Dimensions ALNV 30-SI, ALNV 45-SI-100, ALNV 60-SI, ALNV 90-S
|
|
The position of the terminal blocks can vary. |
| Dimension |
ALNV 30-S |
ALNV 30-S |
ALNV 90-S |
ALNV 45-SI-100 |
ALNV 60-SI |
|---|---|---|---|---|---|
|
A |
155 ±2 |
95 ±2 |
205 ±2 |
175 ±2 |
205 ±2 |
|
B |
75 ±2 |
66 ±2 |
84 ±2 |
76 ±2 |
94 ±2 |
|
C |
151 ±10 |
140 ±10 |
230 ±10 |
208 ±3 |
230 ±10 |
|
D |
135 ±1 |
63 ±1 |
185 ±1 |
155 ±1 |
185 ±1 |
|
E |
56.7 ±1 |
50 ±1 |
65 ±1 |
54 ±3 |
67 ±1 |
|
F |
7.0 *) |
5.8 |
9.0 *) |
9.0 *) |
9.0 *) |
|
G |
12.0 *) |
11 |
16.0 *) |
16.0 *) |
16.0 *) |
|
H |
0 |
0 |
0 |
28 ±3 |
0 |
|
AMK part no. |
O950 |
O828 |
O890 |
O951 |
O894 |
| *) | Siehe 'Detail of mounting hole'. |
